Liquid Injection System (LIS)
The LIS is the first technology allowing for automatic, parallelized feeding of liquids in shake flasks.
Overview
Open a whole new world of bioprocess development when you use LIS to perform automatic feeding in shake flasks. Simply assemble the components, define the experiment parameters, fill the cartridge with the feeding liquid, and start feeding. The user-friendly software allows you to control and monitor your feeding experiments wirelessly.
- Automated feeding of liquids into shake flask cultures
- Flexible feeding rates: From 100ul droplets to 1 ml/min continuous feeding
- Control and monitor your feeding experiments wirelessly with the LIS software
- Introduce bioreactor-like feeding and control options to your shake flask
- For a broad variety of applications (e.g. Fed-Batch, pH control or automated inoculation)
What Our Customers Are Saying
-Prof. Dr. -Ing. Frank Eiden (Westphalian University of Applied Science)

-FermFactory (RWTH Aachen University)

How it Works
Automation enables the use of complex feeding schedules

In order to dispense a defined amount of liquid from the cartridge, the drive pumps air through a sterile filter into the cartridge according to the feeding profile.

After the dispense step, the drive rebuilds negative pressure to keep the remaining liquid in the cartridge.
Hardware & Software Components
LIS Drive

The drive is a programmable miniature pump that controls when and how much liquid is fed from the cartridge into the flask.
LIS Cartridge

The cartridge is a pre-sterilized, ready-to-use container that fits on top of the shake flask. It can be filled with up to 25 mL of any type of liquid and acts as a reservoir during the feeding experiment.
LIS Software
.png)
The software, when paired with a coordinator, allows you to wirelessly control and monitor your feeding experiments. In the software you can create individual feeding profiles, define essential feeding parameters, and archive experimental data.
Specifications

Compatible Laboratory Infrastructure
The LIS is designed to fit any 38mm straight neck Erlenmeyer shake flask.
-
Any shake flask size ranging from 100mL to 5000mL
-
Flasks with or without baffles
-
Glass and single-use plastic flasks
-
Spring clip and sticky plate mounts
LIS has been successfully tested with a broad variety of liquids. Our team of application scientists will work with you to ensure that the liquid and concentration needed for your particular application can be used with our feeding system.
-
Sugars
-
Alcohols
-
Glycerol
-
Acids, bases, and inductors (e.g., IPTG)
-
Antifoam

Compatible Laboratory Infrastructure
The LIS is designed to fit any 38mm straight neck Erlenmeyer shake flask.
-
Any shake flask size ranging from 100mL to 5000mL
-
Flasks with or without baffles
-
Glass and single-use plastic flasks
-
Spring clip and sticky plate mounts
LIS has been successfully tested with a broad variety of liquids. Our team of application scientists will work with you to ensure that the liquid and concentration needed for your particular application can be used with our feeding system.
-
Sugars
-
Alcohols
-
Glycerol
-
Acids, bases, and inductors (e.g., IPTG)
-
Antifoam
